技術特性表
|
名稱 |
指標 |
|
公稱直徑(mm) |
150-1300 |
|
允許工作壓力(Mpa) |
PN≤0.25 |
|
允許工作溫度(℃) |
0-200 |
|
玻璃層耐溫急變(℃) |
熱120 冷110 |
A型塔節(jié)尺寸表
|
DN |
D |
D1 |
D2 |
H |
H1 |
S |
L≤ |
N-￠ |
總重(Kg) |
|
150 |
130 |
260 |
300 |
49 |
14 |
6 |
1000 |
8-18 |
29 |
|
200 |
190 |
310 |
350 |
49 |
16 |
6 |
1000 |
12-18 |
45 |
|
300 |
300 |
425 |
465 |
49 |
20 |
6 |
1000 |
16-20 |
76 |
|
400 |
400 |
535 |
575 |
49 |
20 |
6 |
1000 |
20-20 |
100 |
|
500 |
500 |
635 |
675 |
49 |
24 |
8 |
1000 |
20-20 |
152 |
|
600 |
600 |
740 |
790 |
59 |
24 |
8 |
1500 |
24-23 |
301 |
|
700 |
700 |
850 |
900 |
59 |
24 |
10 |
1500 |
28-23 |
352 |
|
800 |
800 |
950 |
1005 |
69 |
24 |
10 |
1500 |
32-27 |
416 |
|
900 |
900 |
1050 |
1105 |
69 |
26 |
10 |
1500 |
32-27 |
482 |
|
1000 |
1000 |
1150 |
1205 |
69 |
26 |
12 |
2000 |
36-27 |
752 |
|
1100 |
1100 |
1250 |
1302 |
69 |
28 |
12 |
2000 |
40-27 |
830 |
|
1200 |
1200 |
1350 |
1405 |
69 |
28 |
12 |
2000 |
40-27 |
916 |
|
1300 |
1300 |
1450 |
1505 |
69 |
28 |
14 |
2000 |
40-27 |
974 |
B型塔節(jié)尺寸表
|
DN |
D |
D1 |
D2 |
D3 |
D4 |
D5 |
D6 |
n-￠ |
d |
L≤ |
總重(Kg) |
|
150 |
130 |
260 |
300 |
- |
- |
202 |
225 |
8-18 |
18 |
1000 |
305 |
|
200 |
190 |
310 |
350 |
- |
- |
258 |
280 |
12-18 |
18 |
1000 |
44 |
|
300 |
300 |
425 |
465 |
380 |
400 |
- |
- |
16-20 |
- |
1000 |
69.5 |
|
400 |
400 |
535 |
575 |
480 |
500 |
- |
- |
20-20 |
- |
1000 |
90 |
